Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Makita RP0910'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Viele Teile müssen je nach Marke beim Hersteller bestellt werden, dies dauert ein bis vier Wochen. Alle Informationen, die wir haben, befinden sich auf unserer Website. Wir können Sie nicht beraten, was Sie benötigen. Dazu müssen Sie die Maschine zur Reparatur zurücksenden. Bitte beachten Sie bei der Bestellung Folgendes:
Zeichnungen der Makita RP0910
Teileliste der Makita RP0910
| Pos. | Beschreibung | Preis ohne MwSt | Preis inkl. MwSt | |
| Die angegebenen Preise enthalten die Mehrwertsteuer | ||||
| Dopmoer m10 | ||||
| 001 | 252643-6 | 1.32 | 1.57 | |
| Nylon moer M10 | ||||
| 002 | 410129-8 | 1.32 | 1.57 | |
| Stange | ||||
| 003 | 417320-9 | 1.39 | 1.65 | |
| Drukveer 13 | ||||
| 004 | 233287-1 | 1.39 | 1.65 | |
| Diepte instelbout | ||||
| 005 | 265739-4 | 11.64 | 13.85 | |
| Dieptering | ||||
| 006 | 417247-3 | 1.32 | 1.57 | |
| Tapschroef 4x18 | ||||
| 007 | 265995-6 | 0.83 | 0.99 | |
| Abdeckhaube | ||||
| 008 | 417239-2 | 6.88 | 8.19 | |
| Motorgehäuse | ||||
| 010 | 152618-4 | 30.62 | 36.44 | |
| Kroonsteen | ||||
| 012 | 654531-7 | 2.00 | 2.38 | |
| Kondensator | ||||
| 013 | 645253-0 | 4.24 | 5.05 | |
| Kabeltule 10 | ||||
| 015 | 682566-8 | 1.12 | 1.33 | |
| Netsnoer 2x1.00 2.2mtr | ||||
| 016 | 665383-1 | 10.00 | 11.90 | |
| Klemstrip | ||||
| 017 | 687124-5 | 0.83 | 0.99 | |
| Tapschroef 4x18 | ||||
| 018 | 265995-6 | 0.83 | 0.99 | |
| Veldverbinder | ||||
| 019 | 638001-4 | 4.82 | 5.74 | |
| Feld | ||||
| 020 | 634368-8 | 27.95 | 33.26 | |
| Tapschroef Pt 5X55 Hr5001C A | ||||
| 021 | 266095-5 | 0.94 | 1.12 | |
| Kogellager 608ddw | ||||
| 022 | 210005-4 | 4.24 | 5.05 | |
| Isolatiering | ||||
| 023 | 681651-4 | 0.94 | 1.12 | |
| Anker Rp0910 | ||||
| 024 | 516403-3 | 67.98 | 80.90 | |
| Waaier 70 Rp0910 | ||||
| 025 | 240034-3 | 4.24 | 5.05 | |
| Tussenplaat Rp0910 | ||||
| 026 | 413078-8 | 2.71 | 3.22 | |
| Verzonken schroef M4x14 | ||||
| 027 | 251295-0 | 0.83 | 0.99 | |
| Lagerborging 50 | ||||
| 028 | 285657-0 | 1.39 | 1.65 | |
| Sluitring 17 | ||||
| 029 | 267114-0 | 0.83 | 0.99 | |
| Kogellager 6203dw | ||||
| 030 | 211278-2 | 8.80 | 10.47 | |
| Schakelaar deksel | ||||
| 031 | 417251-2 | 8.80 | 10.47 | |
| Stofafzuigvoet | ||||
| 032 | 417256-2 | 2.27 | 2.70 | |
| Schroef 4x14 | ||||
| 033 | 911121-2 | 0.83 | 0.99 | |
| Schakelaarzijhandgreep | ||||
| 034 | 417250-4 | 5.44 | 6.47 | |
| Schakelaar Sw-45 | ||||
| 035 | 651834-0 | 7.81 | 9.29 | |
| Tapschroef 4x18 | ||||
| 036 | 265995-6 | 0.83 | 0.99 | |
| Schroef 6x20 | ||||
| 037 | 911333-7 | 0.83 | 0.99 | |
| Schakelaartrekker | ||||
| 038 | 417254-6 | 2.98 | 3.55 | |
| Drukveer 8 | ||||
| 039 | 233288-9 | 0.83 | 0.99 | |
| Ontgrendelknop | ||||
| 040 | 417255-4 | 1.92 | 2.28 | |
| Schroef 4x18 | ||||
| 042 | 911133-5 | 0.83 | 0.99 | |
| Abdeckhaube | ||||
| 043 | 417241-5 | 10.00 | 11.90 | |
| Motorsteun | ||||
| 044 | 152619-2 | 65.26 | 77.66 | |
| Schaalverdeling | ||||
| 045 | 816792-9 | 3.37 | 4.01 | |
| Koolborstel set Cb-303 | ||||
| 047 | 191963-2 | 4.82 | 5.74 | |
| Koolborstelhouderdop | ||||
| 048 | 643750-0 | 0.83 | 0.99 | |
| Afdekkap voor knop | ||||
| 049 | 417249-9 | 6.86 | 8.16 | |
| Zeskantbout M8 X 35 | ||||
| 050 | 265479-4 | 0.83 | 0.99 | |
| Knopf | ||||
| 051 | 417248-1 | 7.81 | 9.29 | |
| Sperrbolzen | ||||
| 052 | 323856-7 | 1.32 | 1.57 | |
| Drukveer 12 | ||||
| 053 | 231231-2 | 0.83 | 0.99 | |
| Moerbus + Knop Cpl | ||||
| 054 | 153476-1 | 10.00 | 11.90 | |
| Nicht mehr lieferbar | ||||
| 055 | 266012-5 | |||
| Lagerafdekking | ||||
| 056 | 285701-3 | 6.08 | 7.24 | |
| Lagerhuisdeksel | ||||
| 057 | 317365-6 | 10.00 | 11.90 | |
| Drukveer 8 | ||||
| 058 | 233072-2 | 0.83 | 0.99 | |
| Druckknopf | ||||
| 059 | 417253-8 | 1.92 | 2.28 | |
| Pin 4 | ||||
| 060 | 256437-1 | 1.12 | 1.33 | |
| Schroef 4x18 | ||||
| 061 | 911133-5 | 0.83 | 0.99 | |
| Spantangset 8mm bovenfrees | ||||
| 062 | 193178-7 | 27.50 | 32.72 | |
| Stofgeleiderkap | ||||
| 063 | 417246-5 | 2.26 | 2.69 | |
| Stofgeleider | ||||
| 064 | 417245-7 | 3.37 | 4.01 | |
| Geleiderpen | ||||
| 065 | 417252-0 | 1.92 | 2.28 | |
| Drukveer 11 * | ||||
| 066 | 233286-3 | 1.32 | 1.57 | |
| Kruiskopschroef 4x11 | ||||
| 067 | 265028-7 | 1.12 | 1.33 | |
| Blokkeerstang | ||||
| 068 | 417257-0 | 1.92 | 2.28 | |
| Voetzool | ||||
| 069 | 152617-6 | 83.68 | 99.58 | |
| Borgplaat 16 Rp0910 | ||||
| 070 | 259037-6 | 0.83 | 0.99 | |
| Voetplaatje | ||||
| 071 | 413079-6 | 7.81 | 9.29 | |
| Verzonken schroef 4x10 | ||||
| 072 | 912112-6 | 0.83 | 0.99 | |
| Drukveer 7 | ||||
| 073 | 231240-1 | 0.83 | 0.99 | |
| Schroef 5x15 | ||||
| 074 | 265740-9 | 2.98 | 3.55 | |
| Zeskant moer M5 | ||||
| 075 | 931202-6 | 0.83 | 0.99 | |
| Zeskant bout 5x16 | ||||
| 076 | 265333-2 | 0.83 | 0.99 | |
| Zeskant moer M5 | ||||
| 077 | 931202-6 | 0.83 | 0.99 | |
| Veldbout M5x40 | ||||
| 078 | 265336-6 | 0.83 | 0.99 | |
| O-ring 8 | ||||
| 079 | 213030-4 | 0.83 | 0.99 | |
| Kruiskopschroef M6 | ||||
| 080 | 251467-7 | 2.00 | 2.38 | |
| Zeskant moer M5 | ||||
| 082 | 931202-6 | 0.83 | 0.99 | |
| Zeskant bout 5x28 | ||||
| 083 | 265335-8 | 0.83 | 0.99 | |
| Drukveer 5 | ||||
| 084 | 231419-4 | 0.94 | 1.12 | |
| Stalen kogel 7.0 | ||||
| 085 | 216022-2 | 0.83 | 0.99 | |
| Drukveer 5 | ||||
| 086 | 231419-4 | 0.94 | 1.12 | |
| Moerbus + Knop Cpl | ||||
| 087 | 153476-1 | 10.00 | 11.90 | |
| Drukveer 8 | ||||
| 088 | 233288-9 | 0.83 | 0.99 | |
| Drukveer 7 | ||||
| 089 | 233127-3 | 0.83 | 0.99 | |
| Spons ring | ||||
| 090 | 685722-9 | 1.92 | 2.28 | |
